10/100BaseTX
Ethernet to fiber FX converter |
10/100BaseTX Ethernet to MM fiber 10/100FX converter
Multi-Mode fiber,
DC power or AC powered
|
•Automatic MDI / MDI-X crossover for
plug-and-play
•Each port supports both 10/100 Mbps speed auto
negotiation
•Store-and-forward architecture
•Full duplex IEEE 802.3x and half duplex backpressure
flow control
•1.4Gbps high performance memory bandwidth.
•Frame buffer memory : 512 Kbit
•Integrated look-up engine with dedicated 1 K
unicast MAC addresses.
•MTBF = 438,000 hours ( Temperature is 25 °)
•MTBCF = 525,600 hours ( Temperature is 25 °)
•Supports +10~+30Vdc voltage Reverse Polarity Protection
•Supports operating temperatures from 0 ~ +70°C
•DIN rail mount for industrial usage |
 |
|
The ANS-200FT is a Ethernet(10/100Base-TX) to Fiber
Optic(100Base-FX) converter. The Ethernet supports 10/100M auto-negotiation
feature and auto MDI/MDIX function.
The ANS-200FT operates at either half or full duplex mode. In full duplex mode,
range is 2km with 62.5/ 125μm fiber cables; in half duplex mode, range is 412m
with 62.5/ 125μm fiber cables.
It contains "soft start" function with overload protection, high-low voltage
protection.
The width of the ANS-200FT is just 32.30 mm, so it can be used where space is
important.
|
ANS-200FT |
Industrial 10/100 Base-T to
100 Base-FX Fiber Optics Converter |
|
ANS-200FT CR |
Industrial 10/100 Base-T to
100 Base-FX Fiber Optics Converter (RoHS) |
AC power options
see other
SCADA
data commutations products
